Ventilated Pellet Stove Anselmo Cola PUPILLA 11.01 kW in Steel-Majolica Integrated Wi-Fi with PDA Included - Available in various colors

Technical features

• Model: Pupil
• Heatable volume: 314 m³
• Color: Ivory, burgundy, black, rust

Performance

• Power introduced: 12.03 kW
• Reduced power: 3.3 kW
• Nominal heat output: 11.01 kW
• Reduced thermal power: 3.1 kW
• Hourly fuel consumption: 0.68 ~ 2.48 kg/h
• Emission: 0.014 ~ 0.02%
• Dust emission: 10.7 ~ 18.0 mg/m³
• Flue gas outlet temperature: 63.3° ~ 154.7 °C
• Efficiency: 91.47 ~ 95.35%
• Chimney draft: 10 ~ 14 Pa
• Tank capacity: 20 kg

Electrical data

• Power (V,Hz, Ø): 220~240/50/1
• Electrical absorption: W 420 start - 120

Installation data

• Fume exhaust diameter: 80 mm
• Air intake diameter: 50 mm
• Minimum rear safety distance: 200 mm
• Minimum side safety distance: 300 mm
• Minimum safety distance right, left and floor: 0 mm

Dimensions and weight

• Dimensions (WxHxD): 524x1040x539 mm
• Weight: 102.0 kg

FIRST IGNITION EXCLUDED

Functionality, technology and design to offer a new form to tradition; the natural heat of the fire in the heart of the homes. Transforming simple heat sources into furnishing elements, capable of giving personality to environments with the quality and style of Made In Italy.

Performance and eco-sustainability combine with savings and beauty

All models are designed and produced according to principles that, over time, have become company culture: performance, research into shapes, savings and ecology. The use of renewable fuels together with the low emissions of our products guarantee environmental respect and sustainability.
The design philosophy of the appliances is based on the exchange of heat on all sides of the combustion chamber.
Derived directly from experience in wood-burning stoves, the system guarantees gradual and natural heating of the environment, greater silence and excellent performance thanks to a large exchange surface. Try the Eco and Stand-by functions to reduce consumption and increase the thermal efficiency of the stove.

Connectivity The evolution of control

Darwin Evolution, the new Anselmo Cola App is available for the AppStore, PlayStore and Microsoft Store. It works through the Wi-Fi kit to be installed on the stove and allows you to conveniently program switching on and off, adjust power and temperatures with a simple touch, wherever the customer is.

Through the new Bluetooth option, however, the customer will be able to control his device without internet connectivity using the smartphone as an advanced remote control

The pellets

Pellets are fuel classified as biomass obtained from the remains of wood processing. In addition to being eco-sustainable and economical, it has a high calorific value which, combined with Anselmo Cola combustion technology, obtains yields above 90% and low CO₂ and NOx emissions.

Clean Air

Aria Pulita, the quality certification of wood and pellet heating, was created to help improve air quality, health and the environment, based on three cornerstones: transparency, objectivity, clarity.

It is a certification system established and promoted by AIEL, the Italian agroforestry energy association, which certifies the suitability of woody biomass heating systems to ensure specific performance, expressed in terms of efficiency and emissions, with particular reference to dust and oxides of nitrogen. Aria Pulita allows each certified heat generator to be assigned a quality class, consistent with the guaranteed quality levels. The different quality classes are identified by an increasing number of "stars" varying from 1 to 4, which correspond to the measurement of the degrees of merit of the performances found. All Anselmo Cola pellet products are 4-star certified.

• Painted steel cladding
• Top and front in majolica
• Door with silk-screened ceramic glass
• High efficiency combustion chamber
• 3 tangential fans
• Anti-explosion valve
• Preheated combustion air
• Cast iron brazier with post combustion
• Removable ash drawer
• Removable handle
• Handheld
• Emergency display

Product Warranty: All products on sale on our site are new and packaged. The warranty on this item is 24 months from the date of purchase.
