Daitsu Air Conditioner Fujitsu Group Dual Split Inverter 9+12 ASD912UI R410 9000+12000

Technical features

Model:

• Catalog code: 3NDA8305
• Model: ASD912UI
• Type: INVERTER

Energy efficiency:

• SEER 5.60
• SCOP 3.80
• Cooling energy class A+
• Heating energy class A

Performance:

• Cooling Capacity (W): 2,600 + 3,500
• Heating Capacity (W): 2,800 + 3,800
• Indoor unit sound pressure level High / Medium / Low dB(A) 34 / 31 / 28 - 34 / 32 / 30
• Max external unit sound pressure level dB(A) 63
• Indoor unit fan flow rate Min / Max m3/h: 410 / 380 / 320 - 500 / 420 / 350
• External unit fan flow rate Max m3/h: 3200

Electrical data:

• Power (V/Hz/Φ): 230/50/1
• Heating Absorbed Power (kW): 1.56
• Power Absorbed Cooling (kW) :1.55

Characteristics:

• Refrigerant gas: R410A
• Liquid / Gas pipe diameter l” 1/4”-3/8”
• Pipe length (Max) Total / Vertical m 20 / 10
• External temperature range in cooling °C +18/+43
• External temperature range in heating °C -7/+24

Dimensions and weight:

• Internal Unit Dimensions (LxHxD): 790 x 265 x 170
• Internal Unit Weight: 9 Kg
• External Unit Dimensions (LxHxD): 955x700x396 mm
• External Unit Weight: 50 Kg

---

WALL MULTISPLIT INVERTER A+ ASD912UI

The new Daitsu range presents a new elegant and compact design with soft lines that can be integrated into any environment. In particular, it offers great savings and an excellent balance between the level of comfort and energy saving.

It stands out in particular for the great savings offered, with a perfect balance between the level of comfort and the lowest possible consumption thanks to the "Energy Saving" mode. The “Low Voltage Start up” function allows the unit to start up correctly in places where the current is unstable or low. (170~265V).

Product specific performance:

• TURBO: increases the cooling or heating power to accelerate the air conditioning of the room and quickly reach the desired temperature.

• X-FAN: With the X-Fan function the fan continues to run to eliminate humidity. This prevents the appearance of mold, keeping the unit clean and healthy.

• SWING : the air outlet flaps move vertically and automatically to distribute the air evenly.

• LIGHT : The function allows all the internal unit indicator lights to be turned off

• SLEEP : Adjusts the room temperature level for maximum comfort and energy saving.

• FOUR AIR SPEEDS:

  - High: for optimal dehumidification;
  - Medium: for normal operation;
  - Low: for silent operation;
  - Auto option: Select the appropriate speed at all times.
  - Ventilation: operation option in ventilation mode.

• TEST : Check the operation of the equipment and display the error code on the indoor unit panel.

• TIMER : allows complete programming.

• DRY : reduces the humidity in the room

---

Product Warranty: All products on sale on our site are new and packaged. The warranty on this item is 24 months from the date of purchase

• peso: 55.0 kg
• classe energetica raffreddamento: A++
• classe energetica riscaldamento: A+
• costospedizionecad: IT35;AD165;AT106;BE111;BG136;HR123;DK175;EE170;FR144;DE102;LV131;LT123;LU80;NL119;PT114;CZ90;SK101;SI101;ES104;SE212;HU85;CH168;
• gas: R-410
• marca: Daitsu
• metri quadri : 25/35
• modello: Daitsu 9+12
• potenza btu: 9000+12000
• superficie riscaldabile mq: 25/35
