Immergas Condensing Gas Boiler VICTRIX 32 TT PLUS Methane/LPG Heating Only Complete with fume exhaust kit

To convert to LPG, contact your local Authorized Assistance Centre

Technical features

• Model: Victrix 32 TT PLUS
• Product code: 3.025515
• Energy Efficiency Class in Healthcare: A
• Load profile: XL
• Maximum nominal heat input in DHW: 34.9 kW
• Maximum nominal heat input in heating: 32.7 kW
• Maximum useful power in DHW: 34.2 kW
• Maximum useful power in heating: 32.0 kW
• Minimum useful thermal power: 3.9 kW
• Useful thermal efficiency at 100% Pn (80/60 °C): 97.8%
• Useful thermal efficiency at 30% of the nominal load. (80/60 °C): 103.2 kW
• Useful thermal efficiency at 100% Pn (40/30 °C): 106.2 %
• Useful thermal efficiency at 30% of the nominal load. (40/30 °C): 108.2%
• Specific flow rate in continuous domestic water service (∆T 30 °C): 23.3 l/min
• Nominal heating expansion tank capacity: 10 litres
• Electrical protection degree: IP X5D

Dimensions and weight

• Dimensions (HxWxD): 748x440x255mm
• Empty weight: 32.4 kg

Immergas Victrix TT PLUS Instant mural

High hydraulic performance The innovative condensing module guarantees high flow rate, low risk of clogging due to impurities in the system water, greater resistance to corrosion thanks to the special alloy

Kettle Prepared as standard for combination with a kettle with a capacity of 80 up to 2000 litres, it guarantees high production of hot water

Fan Heating Unit The combination with a water air heater allows rapid heating of the rooms. Ideal for workshops, public spaces, gyms, etc.

High seasonal yields The wide modulation range of the boiler allows high seasonal yields with consequent reduction in gas consumption

Optional thermoregulators Improve comfort and increase energy savings.

Optional DOMINUS App Simple and intuitive, it allows you to check the functioning and temperature of the boiler, activate its switching on and off from anywhere via smartphone or tablet

Formula Comfort 10 It uses the most complete maintenance program lasting 10 years without activation costs, with the possibility of extending it up to 15 years. In collaboration with the Immergas Authorized Assistance Centre, it can be activated during the initial check

Eco-compatible technology Complies with the European ErP and ELD Directives, allowing high energy efficiency classes to be achieved in heating and hot water production

Ecological class 5 The best for reduced nitrogen oxide emissions

Renewable energy Using a boiler with a capacity of 120 liters or more, the boiler can be connected to solar thermal systems for greater production of hot water. It can also be combined with hybrid systems with heat pump

Maximum flexibility Approved to work indoors, built-in and outdoors, even in the open air. IPX5D electrical protection. Antifreeze as standard down to -5 °C

Maximum compactness Only 25 cm deep

Product Warranty: All products on sale on our site are new and packaged. The warranty on this item is 24 months from the date of purchase.

• peso: 35.0 kg
• classe energetica riscaldamento: A
• gas: Methane/LPG
• marca: IMMERSION
• metri quadri : 220
• modello: Victrix_32TT_Plus
• potenza in kw: 32
• potenza nominale: 32
• superficie riscaldabile mq: 220
