Toshiba Inverter Air Conditioner AKITA EVO II Hi-Wall series 22000 Btu RAS-B22N3KV2 R-32 Wi-Fi Optional

Toshiba Inverter Air Conditioner AKITA EVO II Hi-Wall series 22000 Btu RAS-B22N3KV2 R-32 Wi-Fi Optional

Technical features

Model:

• Indoor unit catalog code: RAS-B22N3KV2-E1
• Outdoor unit catalog code: RAS-22N3AV2-E
• Type: heat pump

Energy efficiency:

• SEER 6.5
• SCOP 4.0
• Cooling energy class A++
• Heating energy class A+
• Annual energy consumption cooling/heating kWh/a: 323/1645

Performance:

• Cooling Capacity (kW): 6.0
• Heating Capacity (kW): 7.0
• Sound pressure level (Quiet-Low-High) dB(A) 33/35/47
• Max external unit sound pressure level dB(A) 53

Electrical data:

• Power (V/Hz/Φ): 230/50/1
• Heating Absorbed Power (kW): 2.0
• Power Absorbed Cooling (kW) : 2.1

Characteristics:

• Refrigerant gas: R410A
• External temperature range in cooling °C -10~46
• External temperature range in heating °C -15~24

Dimensions and weight:

• Internal Unit WxHxD (mm): 320 x 1050 x 229; 13 kg
• External Unit WxHxD (mm): 550 x 780 x 290; 41 kg

General characteristics

TOSHIBA

Toshiba's four pillars of environmental protection

The Toshiba Group has developed an Environmental Action Plan as the backbone of its “Goal 2050” to become one of the world's leading companies in respecting and protecting the environment. It is based on four main pillars which are:

• the environmental development of the Products, to obtain the minimum environmental impact for their entire life cycle;
• the development of technologies to minimize CO2 emissions into the atmosphere;
• the development of production processes to minimize their impact on the environment;
• corporate management in an environmental sense both through communication and that all basic employee activities are activated for continuous improvement in an environmental sense.

• Quality and environment

Toshiba is committed to developing air conditioning technology that protects the environment, ensuring quality, safety and reliability for users around the world. This attention is demonstrated and recognized by international awards received for the production of products characterized by high energy savings and for the related production systems oriented towards the protection and safeguarding of the territory. Furthermore, the attention to the containment of CO2 emissions, the importance already in the design phase of recycling up to 90% of the components, the design and development of products optimized for HFC refrigerants denote Toshiba's concrete commitment to the defense and sustainability of 'environment. To certify and guarantee the reliability of its technical data, Toshiba adheres to the Eurovent certification program, which subjects products to tests to verify conformity between declared data and the actual performance achieved.

• Silence

The environments where Toshiba systems operate are extremely comfortable and quiet. The analysis and study of air flows and paths, carried out in our laboratories, guarantee excellent performance in terms of perception of silence. Furthermore, the use of advanced technologies such as Twin Rotary compressors guarantees high energy performance. The more uniform rotation of the system components allows for a notable reduction in vibrations, with a clear positive effect also on the reliability of the system and on the silence of the entire refrigeration circuit compared to a traditional scroll compressor.

• Affordability

Toshiba heat pumps allow you to access the tariff concessions and incentives in force, always check the full compliance of the specific application with the legal requirements. For "energy retrofits", one of the conditions is that the systems meet the specific minimum efficiency requirements.

• The residential range, the applications

The air conditioning of residential environments is essential for the well-being of the person, both at home and in the work environment. The air conditioner, in fact, not only guarantees the maintenance of the desired temperature, but also a high level of air quality in the environment in which we live. Choosing the most suitable system is the key to optimizing performance and comfort . The air treatment, the low noise levels, the guaranteed energy savings and the simple installation of the internal unit are factors that make the Toshiba residential line the best choice for every home.

The new residential air conditioners have been designed to offer users the maximum possible comfort. The sophisticated filtration systems guarantee environments with constantly clean air. In fact, the new hi-walls combine minimal energy consumption with the best quality of ambient air. Thanks to their elegant line and innovative design, the indoor units adapt perfectly to any environment and interior architecture. They have all the features requested by users: they are silent, discreet and unobtrusive, providing high energy efficiency and complete air purification.

AKITA EVO II Hi-wall inverter

This wall unit model is compact and the elegance of the design allows it to be integrated into any architecture and furnishings.

The Akita EVO II family has a clean and elegant design that allows it to be integrated into any architecture and furnishings. The complete range, with sizes available up to 7 kW, the wide spectrum of operating temperatures, from -15°C in heating up to +46°C in cooling, and the excellent energy efficiency in every operating mode make it the ideal product to satisfy the needs of every type of customer for a vast field of applications.

Mono and multi compatibility allows different systems to be integrated into the same application while preserving aesthetic continuity.

The presence of the " One Touch " button on the remote control guarantees the user immediate comfort with a single touch.

Attention to the user's well-being translates into a series of features ranging from the Quiet function , a silent mode activated by remote control for optimal acoustic comfort, to the advanced filtration system for cleaner ambient air, to the " Preset " for storing your favorite settings and activating them at the touch of a button.

The internal unit is self-cleaning : after the unit is turned off the fan continues to operate for up to twenty minutes to dry the heat exchange coil and eliminate any residual humidity still present.

The noise level is among the lowest in its category and, for optimal comfort, it is equipped with the quiet function selectable by remote control.

This model is the perfect choice both for its superior energy efficiency and for complete air purification thanks to the " New IAQ Filter " filtration system.

Total remote control (optional)

The convenience of being able to easily manage the air conditioner remotely is really useful. Switching on and off, setting the temperature and fan speed remotely guarantees ideal temperatures and energy savings. Toshiba offers two solutions to meet every need.

- Wi-Fi Combi Control Allows you to manage the operation of the air conditioner from a mobile phone via SMS: you just need to insert the SIM card into the Combi Control and use the intuitive graphic applications for Android and Apple.

- Toshiba & Wi-Fi Thanks to the connection with the home or office Wi-Fi network, it allows remote control of the air conditioner, directly from smartphones, tablets and PCs.

Characteristics :

• Excellent efficiency guarantees minimum energy expenditure in cooling with SEER in class A++ and in heating with SCOP up to class A+ (sizes 10, 13, 18 and 22).
• Quiet function: silent mode activated by remote control for optimal acoustic comfort.
• Compatible mono and multi indoor units (sizes 10,13,16 and 22).
• Operation at low temperatures -15°C in heating and -10°C in cooling.
• “New IAQ Filter” filtration system with deodorizing, anti-bacterial and anti-virus action.
• One touch preset: function that allows you to store your favorite settings and activate them at the touch of a button.

• peso: 50.0 kg
• classe energetica raffreddamento: A++
• classe energetica riscaldamento: A+
• gas: R-32
• marca: Toshiba
• metri quadri : 60 - 80 m2
• modello: RAS-B22N3KV2
• potenza btu: 22000
