Baxi Dual Split Inverter Air Conditioner Astra 9+12 Series with LSGT50-2M R-32 Wi-Fi Optional 9000+12000 - New
Baxi Dual Split Inverter Air Conditioner Astra 9+12 Series with LSGT50-2M R-32 Wi-Fi Optional 9000+12000 - New is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
How shipping works
How shipping works
I costi di spedizione variano a seconda del peso e della modalità di spedizione dell'ordine.
I nostri servizi di spedizione:
- Spedizione standard: consegna stimata dai 2 ai 5 giorni lavorativi
- Spedizione Premium: consegna garantita in 24 ore lavorative
- Spedizione Premium + Consegna al piano: consegna garantita in 24 ore lavorative
Consulta le tabelle per i prezzi della spedizione standard per l'Italia e per le Isole Minori e Zone Disagiate.
Per ulteriori dettagli sulla Spedizione Premium, consulta la pagina di spedizione premium.
Servizio clienti
Servizio clienti
Il nostro servizio di assistenza è dedicato a fornire supporto ai nostri clienti per qualsiasi problema o domanda che possano avere prima o dopo l’acquisto dei nostri prodotti.
Utilizza il canale di comunicazione diretta per parlare con un nostro operatore, oppure inviaci una mail ad uno degli indirizzi elencati nella pagina contattaci.
Il nostro team di assistenza clienti è composto da professionisti altamente qualificati e sempre pronti ad aiutare i clienti a risolvere qualsiasi problema o rispondere a qualsiasi domanda in modo rapido ed efficiente. Ci impegniamo a garantire la massima soddisfazione del cliente e a fornire un servizio di assistenza post-vendita di altissima qualità. Quindi, se hai bisogno di assistenza, non esitare a contattarci; saremo lieti di aiutarti in ogni modo possibile.
Description
Description
Technical features
Internal Units
1) Model
- Indoor Unit Catalog Code: 1x JSGNW25
- Power: 9000 btu/h
- Cooling Capacity: 2.55 kW
- Heating Capacity: 2.65 kW
- Power absorbed: 40 W
- Treated air: 600 m 3 /h
- Sound Power Level: 53 dB(A)
- Liquid pipe diameter: 6.35 mm (1/4")
- Gas pipe diameter: 9.52 mm (3/8")
- Internal Unit Dimensions (WxHxD): 792x292x201 mm
- Internal Unit Weight: 8.0 Kg
- Wi-Fi Optional ( Air Connect )
2) Model
- Indoor Unit Catalog Code: 1x JSGNW35
- Power: 12000 btu/h
- Cooling Capacity: 3.6 kW
- Heating Capacity: 3.7 kW
- Power absorbed: 40 W
- Treated air: 600 m 3 /h
- Sound Power Level: 52 dB(A)
- Liquid pipe diameter: 6.35 mm (1/4")
- Gas pipe diameter: 9.52 mm (3/8")
- Internal Unit Dimensions (WxHxD): 792x292x201 mm
- Internal Unit Weight: 8.0 Kg
- Wi-Fi Optional ( Air Connect )
External Unit
Model:
- Indoor Unit catalog code: LSGT50-2M
- Max indoor units: up to 2 indoor units
Energy efficiency:
- SEER : 7.0
- SCOP : 4.0
- Cooling Energy Efficiency Class: A++
- Heating Energy Efficiency Class: A+
Performance:
- Cooling Capacity: 5.3 kW
- Heating Capacity: 5.6 kW
- Std Cooling absorption: 1.63 kW
- Std Heating absorption: 1.49 kW
- Sound power level: 62 dB(A)
Characteristics:
- Power (V/Hz/Φ): 220~240/50/1
- Refrigerant gas: R-32
- Pipe diameter Liquid: 6.35 mm (1/4") x2
- Gas pipe diameter: 9.52 mm (3/8") x2
- Maximum length of pipes: 40 m
- Maximum height difference Internal Unit / External Unit: 15 m
Dimensions:
- External Unit Dimensions (WxHxD): 800x545x315 mm
- External Unit Weight: 36 Kg
Baxi Astra
New matt white and modern design
Totally new, minimal and elegant design with matt white surfaces. The front panel has a strongly vertical cut which makes the design harmonious and exclusive.
Structure of the new Baxi Astra
Lower attacks
It is possible to mount the internal unit on the wall before connecting the pipes, without having to dismantle the entire casing; Furthermore, there is no need to tilt the unit to make connections. This reduces installation times.
Fins
Baxi Astra is equipped with a double set of vertical and horizontal fins, with leaf-shaped fins for uniform air distribution.
Knobs instead of locking screws
Instead of traditional screws, there are locking knobs for dismantling the plastic casing
Total climate control
Easy and intuitive comfort management
Comfort is managed locally thanks to the remote control with liquid crystal display supplied as standard and complete with double keyboard with quick menu on the surface.
Richness of exploitable functions
Smart comfort with Air Connect comfort within reach of your smartphone
The Air Connect App and the WI-FI module allow you to remotely control Baxi Astra air conditioners.
The WI-FI module of the Baxi Astra range consists of a Plug & Play USB device that is extremely simple to install.
Air Connect is the application that allows you to have full control of the temperature and comfort of your home, at any time and from wherever you are.
For the Baxi Astra range, the WI-FI module is available as an accessory. Therefore, after installing the WI-FI module and downloading the App, you can communicate with your Baxi air conditioner directly from your Smartphone and Tablet devices (iOs and Android).
With a simple touch you can: turn the air conditioner on/off, set operating modes, fan speed, vertical and horizontal oscillation of the louvers, active functions, timer, etc.
Air Connect means practicality and ease of use:
- No visual impact: the WI-FI module is inserted in the appropriate housing behind the front panel of the air conditioner
- Easy and intuitive time programming that allows the combination of comfort and high energy savings
- Possibility of controlling multiple appliances with the same App, in the case of Multi Split air conditioners (Dual Split, Trial Split, etc.) equipped with the WI-FI module
- Presence of all the remote control functions directly on your device, such as: Turbo, Sleep, iClean, etc
WI-FI module packaging
The package contains: physical WI-FI module, manual and warranty certificate
Terms of Use
This application is able to manage more than one device (air conditioner) as long as they are Baxi air conditioners, equipped with the appropriate WI-FI module.
A Complete Range
With the new range of Baxi Astra air conditioners it is possible to create multiple combinations to satisfy the most varied installation needs: MONO, DUAL, TRIAL, QUADRI and PENTA Split. For the Multi Split models of the Baxi Astra range, the diagram shows, by way of example, a typical combination and the maximum achievable for each configuration
Cutting-edge technology
DC inverter technology, managing the air supply based on the real needs of the environment, guarantees the optimization of consumption and the reduction of noise thanks to:
- Internal DC fan
- External DC fan
- DC compressor
- Machine controller
The best synthesis between functionality and performance
Silent
Baxi Astra air conditioners are designed for highly silent operation (up to max 20 dBA) to guarantee quality comfort in the environment in which we stay.
Product Warranty: All products on sale on our site are new and packaged. The warranty on this item is 24 months from the date of purchase.
Scheda Tecnica
Scheda Tecnica
- peso: 55.0 kg
- classe energetica raffreddamento: A++
- classe energetica riscaldamento: A+
- gas: R-32
- marca: BAXI
- metri quadri : 25/35
- modello: Astra 9+12 50
- potenza btu: 9000+12000
- superficie riscaldabile mq: 25/35
