Gree Trial Split Inverter Air Conditioning PULAR 9+9+9 series with GWHD(24)NK6OO R-32 Integrated Wi-Fi 9000+9000+9000

Installation Data:

• Pipe diameter Liquid: 6.35 mm (1/4") x3
• Gas pipe diameter: 9.52 mm (3/8") x3
• Maximum pipe length: 30 m
• Maximum length of pipes with additional charge: 60 m
• Maximum height difference between indoor units: 15 m

Dimensions:

---

Gree Pular Purity in design and Comfort

The finish is matte, velvet effect, the color is pure white

Thanks to the use of matte injection molding techniques, simple and easy to match, for a contemporary, captivating style

The design is seamless

The integrated double flap, completely closed, has no joints, because the details make the difference

Cleanliness and linearity are the characterizing elements of the design

Fluid curves and transitions, maximum simplicity, for a minimal approach, ideal for any environment

---

Superior Comfort Pular's advanced functions, capable of providing unprecedented comfort

i-FEEL Plus Now the sensor on the remote control, which measures the room temperature and sends input to the unit to ensure the desired temperature where the remote control is placed, has an even higher input frequency. Every 10 minutes it connects with the unit, ensuring maximum comfort

HOC technology for each mode Cooling with shower air flow. Heating with flow from bottom to top. Air flow increased by 17% compared to previous ranges. Very long air throw, up to 10 m. High precision in air delivery thanks to the double flap

3D Airflow Customize your comfort with the 3D SWING function. Both horizontal and vertical flaps can be individually directed via the remote control. It is possible to select the oscillation angle for both flaps

Multi-speed airflow Up to 7 fan speeds from Quiet to Turbo Auto manages ventilation intelligently

Sleep function with 3 options

• Silent modifies the set point in the following two hours
• Smart intelligently adjusts the set point
• DIY choose your personalized sleep program

Turbo in cold and hot For instant comfort, bring compressor and fans to maximum power

Intelligent car mode Relax and let the air conditioning decide how to behave to achieve the desired comfort. For the first time, even in Auto mode it is possible to select the desired room temperature

Cold air prevention In Heating, a special intelligent function allows the conditioned air to enter the room only if and when sufficiently heated, for maximum comfort.

Save Energy Dedicated to those who want to save as much as possible, they decide the temperature independently, according to the default settings. Operation is managed automatically

Intelligent Auto-restart It guarantees continuity of your comfort because after a blackout the unit automatically restarts when the power is restored, maintaining the last settings.

Low Voltage Startup Intelligently, the unit starts with minimal inrush, so as not to interfere with the use of other household appliances

Intelligent Defrost If the cold external temperature causes the formation of ice on the condensing coil, the correct operation of the air conditioner in hot conditions requires that there is a stop to the introduction of hot air into the room to allow defrosting of the external exchanger. In the specific case, these stops are not scheduled at regular intervals, but take place only if and when truly necessary, guaranteeing continuity of flow of hot air into the room.

Maximum Silence With Pular you can sleep peacefully, it's SUPER QUIET, its sound level is record-breaking! 3 dB(A) below standard values: in Sleep mode it does not exceed 21 dB(A)

---

TOP air quality with the COLD PLASMA PLUS Purification System

Its sterilization effectiveness against bacteria is the best ever: it reaches 93%, compared to an average value of 80% for similar systems. It releases ions capable of neutralizing bacteria, fungi, pollen, mites and, in general, pollutants present in indoor air. Removes over 400 types of odors. It makes the air lighter by enriching it with negative ions

---

Single filter accessible without any disassembly for cleaning

The anti-dust filter is external, integrated into the structure, easy to reach and clean with high frequency, without having to dismantle it. The completely closed double flap has no joints and therefore prevents dust and other pollutants from entering the unit

Optional Filters Even purer air with the new optional filters, which you can apply to the standard Pular filter

Anti-bacterial Filter The structure is made by adding the biological antibacterial agent on the filter mesh. Effectively eliminates Escherichia coli and staphylococcus, etc

Tio ₂ anti-bacterial deodorant filter Takes activated carbon as a carrier, mixed with titanium dioxide

Mite Clear Anti-Mite Filter New anti-mite and antibacterial material and can defend or prevent mite, to improve indoor air quality

Composite filter Silver Ions, Catechin, Mite Clear

• Silver Ions: Effectively eliminates carcinogens, such as staphylococcus, streptococcus, salmonella, etc.
• Catechin: Effectively sterilizes bacteria and other pollutants; prevents the causes of unpleasant odors
• Mild Clear: Defends against mites and effectively prevents their formation

---

Auto-Clean Manage the cleaning of your internal drive with Pular

Condensate, frost, defrost, dry You can decide to activate evaporator cleaning whenever you want: with the unit off, just press two buttons on the remote control. The function will see condensation, ice formation, defrosting and drying phases take place in sequence aimed at eliminating all dust and polluting residues and any traces of condensation. This will always allow clean air to be introduced into the environment and preserve the efficiency of the heat exchanger

---

X-Fan

The prevention of mold formation is also guaranteed by this function, which is activated simply by holding down the speed button for 2 seconds: the internal unit fan will continue to work, even with the unit turned off, for a few minutes, in order to dry perfectly the evaporator

---

User Friendly and Smart Controlling Pular's features is a breeze .

By Infrared Remote Control Easy to use

It has a minimal but technological design, pure white finish, high gloss and is characterized by a large LCD display and easy-to-use buttons. The integrated temperature sensor is activated by pressing the IFeel button and the Light button allows you to turn off the backlight of the indoor unit's LED display. The wifi button allows immediate activation of the function on the remote control

From a smartphone, thanks to integrated Wi-Fi as standard across the entire range

Thanks to the very intuitive G+ App, available for download in versions for Android and iOS systems in Google play or App store, you can control all the functions remotely. Downloading and installing the app, connecting to your home WiFi and adding the unit are very simple operations: from your office or sofa at home you can easily control all the parameters of the air conditioner. With the same app you can manage multiple units.

---

Advanced controls

It is possible to centrally manage, via BACNET (BMS) or CENTRALIZED CONTROL or SMART ZONE in combination with wired controls (1 per split unit), even multiple units within the same building (up to 16 with SMART CONTROL - up to 36 with CENTRALIZED CONTROL, up to 255 with BACNET), as if it were a small system

Programmable Wire Control Pular can also be controlled with a wire control, to be installed on the wall. Allows you to program on and off, select the operating mode and speed, flap position, daily timer and weekly programs

Door Control Contact The on/off contact on the unit allows you to manage turning the unit on and off with the magnetic card to open the entrance door (for example of a hotel room). By inserting the card the air conditioner is activated; by removing the card the unit turns off: this avoids wasting energy. For this application, the wired control is required

---

Easy Installation Pular is built with features that facilitate installation, as well as access to parts for maintenance

Easy Maintenance The electrical box and the electronic board are easy to open and remove. The self-diagnosis function, which shows errors on the internal unit display, facilitates the identification of any malfunctions and speeds up their resolution. The special design of the outdoor unit valve cover makes it easier to access the connections.

Application Versatility Up to 5 internal units that can be combined with multi-split external units

---

Green technology

Choose the GREEN technology of GREE air conditioners: renewable energy, which therefore captures the thermal energy present in the air and transfers it where it is needed. The use of R32 refrigerant, with low impact on global warming, makes environmental comfort even greener: there is no impact on the ozone layer and the quantity of gas necessary to ensure good performance is 30% lower than that of previous gases such as R410A, thanks to its higher yield

---

High Energy Efficiency and Low Consumption

Inverter G10 is the latest generation DC Inverter technology that allows you to optimize performance and consumption thanks to the modulation of the compressor and fans according to real comfort needs. In fact, as the desired temperature approaches, both the compressor and the fans of the external and internal units modulate capacity and consumption, ensuring:

• rapid achievement of the desired comfort

• constant maintenance of comfort conditions

• precise temperature control

• containment of consumption

• minimization of the sound level

---

Mono and Multi Compatible

The Pular indoor unit is available for single and multi applications with nominal cooling capacity from 2.7 to 6.5 kW. The internal unit with a capacity of 2.1 kW is dedicated to Dual, Trial and Quadri applications: possible matching and related data will soon be available

---
