Hisense Inverter Air Conditioning HALO series 9000 Btu CBYR0905G + CBYR0905W R-32 Wi-Fi Optional A++/A+

Technical features

• Indoor unit catalog code: CBYR0905G
• Outdoor unit catalog code: CBYR0905W
• Power: 9000 Btu
• Optional Wi-Fi: AEH-W4GX

Energy efficiency

• SEER: 6.3
• SCOP : 4.0
• Cooling energy efficiency class: A++
• Heating energy efficiency class: A+
• Annual energy consumption in cooling: 144 kWh/a
• Annual energy consumption in heating: 770 kWh/a

Performance

• Cooling capacity: 2.6 kW
• Heating capacity: 2.7 kW
• Cooling absorption: 0.745 kW
• Heating absorption: 0.675 kW
• Indoor unit treated air: 9.17 m ³ /min
• Indoor unit sound power level: 57 dB(A)
• Indoor unit sound pressure level: 24~39 dB(A)

Electrical data

• Power (V,Hz, Ø): 220~240/50/1
• Refrigerant gas: R32
• Operating range
• - Cooling: -15° ~ 43° C
• - Heating: -20° ~ 24° C

---

Hisense Halo DC inverter technology

Hisense inverter air conditioners contain advanced technologies to guarantee efficiency, energy saving, silence and comfort

• 180° sine wave technology: More efficient, more stable, longer use

• Magnetic field control for operation even at high frequencies (> 70 Hz): Rapid cooling, rapid heating

• Frequency compensation technology: Constant temperature, Energy saving

• Wide frequency control range: Continuous operation, Accurate control

• 3-D Inverter: High efficiency, Great adaptability, Less maintenance

---

Self clean

Hisense's patented cleaning technology ensures maximum performance of the internal and external unit. The self-cleaning process via freeze, defrost and dry cycle at high temperatures removes dust, bacteria from the units easily and effectively to keep the air conditioner clean and safe. The Self-Clean function is activated by remote control and is available on all wall-mounted indoor units and single-split outdoor units

Anti-mold

Wi-Fi control

Hisense air conditioners can be conveniently managed inside and outside the home with a mobile device and a Wi-Fi connection. HiSmart Life is the simple to use app with an intuitive interface that allows you to control the air conditioner wherever you are. The app is available for iOS and Android.

After downloading the app and pairing the air conditioner, the app allows you to manage operating modes, temperature, ventilation speed and air flow. From the «Smart function» section you can also set daily or weekly timers.

---

Smart voice control

The new HiSmart Life app is compatible with Alexa and Google Assistant: thanks to voice interaction, it is possible to turn it on, off, adjust the temperature and set the desired operating mode (cooling or heating).

You can find HiSmart Life in the Alexa Skills and in the Google Assistant catalogue.

---

Super silent

The advanced control technology and the special design of the fan guarantee maximum silence in Super Silent mode. The air conditioner reaches 19 dB(A) of silence.

---

I feel

The sensor inside the remote control can detect the surrounding temperature and transmit this information to the indoor unit. The indoor unit operates according to the detected temperature. Intelligent temperature control ensures a more comfortable environment and more precise temperature control, saving energy
