Description
Description
Important Notice on Regulations for Fluorinated Gases IN ITALY
In accordance with Regulation (EU) No. 517/2014 and Presidential Decree No. 146/2018, equipment containing fluorinated gases that is not hermetically sealed can only be sold if installed by a certified company.
By law, each sale must be recorded in the Fluorinated Gas Database, including a declaration from the buyer ensuring that the installation complies with the regulations. Therefore, before completing the order, it will be necessary to provide this mandatory declaration.
Technical features
- Indoor unit catalog code: MSZ-HR71VF
- Outdoor unit catalog code: MUZ-HR71VF
- Power: 24000 Btu
- Optional Wi-Fi: MAC-587IF-E
Energy efficiency
- SEER : 7
- SCOP: 4.3
- Cooling energy efficiency class: A++
- Heating energy efficiency class: A+
- Annual energy consumption in cooling: 355 kWh/a
- Annual energy consumption in heating: 1715 kWh/a
Performance
- Cooling capacity: 7.1 kW
- Heating capacity: 8.1 kW
- Cooling power consumption: 2.33 kW
- Heating power consumption: 2.44 kW
- Indoor unit treated air: 10.4 ~ 19.6 m 3 /min
- Indoor unit sound power: 57 dB(A)
- External unit sound power: 66 dB(A)
- Indoor unit sound pressure: 33 ~ 50 dB(A)
- External unit sound pressure: 50 dB(A)
- Power (V,Hz, Ø): 220~240/50/1
- Refrigerant gas: R-32
- Operation range:
- Cooling: -10° ~ +46° C
- Heating: -10 ~ +24° C
- Liquid pipe diameter: 6.35 mm (1/4")
- Gas pipe diameter: 12.70 mm (1/2")
- Maximum pipe length: 30 m
- Maximum height difference between internal unit and external unit: 15 m
Dimensions and weight
- Indoor unit dimensions (HxWxD): 305x923x263 mm
- Internal unit weight: 12.5 kg
- External unit dimensions (HxWxD): 714x800x285 mm
- Outdoor unit weight: 40.0 kg
Mitsubishi Electric Smart HR Series A compact line designed for small spaces
DC Inverter
The Inverter system is an electronic device that allows you to efficiently vary the speed of the compressor and, consequently, the power supplied by the air conditioner based on the cooling or heating request. Compared to traditional fixed speed air conditioners (On/Off), inverter air conditioners reach the required temperature sooner and keep it stable, without annoying changes, to the benefit of comfort and electricity consumption.
R-32
The R32 refrigerant gas complies with European directives on the reduction of the greenhouse effect, presenting a lower GWP than R410A and not damaging the ozone layer. The advantages?
- High energy efficiency
- Reduction in the amount of refrigerant gas used
- Reduced environmental impact
- Easily chargeable and recoverable as pure gas
- Low toxicity and flammability
A compact line designed for small spaces
The MSZ-HR units guarantee comfort and low electricity consumption, with minimal noise emissions without sacrificing compact dimensions.
Compact indoor units
The dimensions of the internal units of the entire range are particularly compact.
This allows installation even in rooms where the space available is limited.
Maximum silence for maximum comfort
The quality of the environment in which we stay also depends on the perceived noise level. Mitsubishi Electric air conditioners help maintain the highest acoustic comfort by reducing noise emissions to a minimum.
MELCloud, Wi-Fi control
MELCloud is the new Wi-Fi control for your Mitsubishi Electric system. By taking advantage of the support of the cloud (the "Cloud") to transmit and receive information and the optional dedicated Wi-Fi interface (MAC-567IF-E), you can easily control your system wherever you are via your PC, tablet or the smartphone; all you need is an internet connection. The MELCloud service was created to have maximum compatibility with PCs, Tablets and Smartphones thanks to dedicated Apps or via Web Browser.
Beyond the A++/A+ class
Operating economy is the great advantage of Mitsubishi Electric air conditioners.
Thanks to the careful design of all components and the use of cutting-edge technologies, energy efficiency reaches extraordinary levels even on a seasonal basis.
In particular, the Smart Line obtains SEER and SCOP (seasonal efficiency indices) values which allow it to reach values beyond Class A++/A+ across the entire range .
Product guarantee: All products on sale on our site are new and packaged. The warranty on this item is 24 months from the date of purchase.
Scheda Tecnica
Scheda Tecnica
- peso: 55.0 kg
- classe energetica raffreddamento: A++
- classe energetica riscaldamento: A+
- gas: R-32
- marca: MITSUBISHI ELECTRIC
- metri quadri : 60 - 80 m2
- modello: MSZ-HR71VF
- potenza btu: 24000
- superficie riscaldabile mq: 70
