Description
Description
PRODUCT AVAILABLE TO ORDER
Overview:
PANASONIC INVERTER FLOOR AIR CONDITIONER CS-Z25UB4EAW + CU-Z25UBEA 9000 BTU.
The versatile, powerful and silent floor-standing units are the ideal solution for every room in your home for every room in your office to enjoy an ideal climate all year round
Technical specifications
Model:
- Internal unit catalog code: CS-Z25UB4EAW
- External unit catalog code: CU-Z25UBEA
- Power (BTU): 9000
Energy efficiency:
- SEER/SCOP (W/W): 6.30/4.30
- Energy Efficiency Class (Cooled): A++
- Energy Efficiency Class (Heating): A+
- Average annual cooling consumption kWh/a: 139
- Average annual consumption in heating. kWh/a: 879
Performance:
- Nominal Cooling Capacity (kW): 2.50
- Nominal heating capacity (kW): 2.88
- Indoor unit sound pressure (dB-A): 34/25/22
- External unit sound pressure (dB-A): 50/51
- External unit sound power (dB-A): 61/62
- External unit sound pressure (dB-A):46/47
Electrical data:
- Power (V/Hz/?): 230
Characteristics:
- Refrigerant gas: R32
Functional field guaranteed:
- - CoolingøC: -10 ~ +43
- - HeatingøC: -15 ~ +24
Dimensions:
- Internal Unit HxWxD (mm): 260 x 575 x 575; 18kg
- Internal Unit Panel HxWxD (mm): 51 x 700 x 700; 2.5kg
- External Unit HxWxD (mm): 542 x 780 x289; 33kg
Technical features
· Environmentally friendly refrigerant R32
· NEW CZ-BT20EW panel
· The cassettes can be controlled via KNX, EnOcean and Modbus
· Designed to be easily installed in false ceilings with a 60x60 opening
· Max length of connection pipes: 30 m (Z50 and Z60)
· Maximum difference in elevation: 20 m (Z50 and Z60)
· Compact external units, easily installed
· High pressure selector in case of high ceilings (>2.7m)
· Drainage pump included (max height difference 750mm)
· Duct for introducing fresh air
Specifications
Specifications
- peso: 35.0 kg
- classe energetica raffreddamento: A++
- classe energetica riscaldamento: A+
- costospedizionecad: IT25;AD113;AT73;BE75;BG88;HR89;DK125;EE122;FR94;DE63;LV94;LT88;LU59;NL68;PT82;CZ66;SK73;SI74;ES75;SE131;HU56;CH135;
- gas: R-32
- marca: Panasonic
- metri quadri : 15-25 m2
- modello: CU-Z25UBEA - CS-Z25UB4EAW
- potenza btu: 9000
- superficie riscaldabile mq: 25
